Flat Bottom Silo
Flat Bottom Silo – Reliable Bulk Grain Storage Solution
A flat bottom silo is the most reliable and cost-effective solution for long-term bulk grain storage. Designed with a flat concrete base, each flat bottom silo is suitable for storing large quantities of grains, oilseeds, pulses, and other free-flowing materials.
Our flat bottom silo is widely used in grain terminals, flour mills, feed mills, breweries, distilleries, and large-scale industrial storage facilities where high capacity and long-term preservation are the key requirements. Proper grain storage using a flat bottom silo significantly reduces post-harvest losses and maintains grain quality. According to the FAO (Food and Agriculture Organization), improved grain storage infrastructure is critical for global food security.
Key Features OF GCT’S SILOS
Heavy-Duty Construction
Built with high-quality galvanized steel sheets for maximum strength and durability.
Large Storage Capacity
Available in a wide range of sizes, from a few hundred tons to several thousand tons (600MT TO 12,500MT).
Aeration System
Ensures proper ventilation and maintains grain quality by controlling temperature and moisture.
Easy Loading & Unloading
Equipped with advanced material handling systems like chain conveyors, bucket elevators, and sweep augers.
Long Service Life
Designed to withstand extreme weather conditions and provide safe grain storage for decades.
Advantages
Ideal for Long-Term Storage
Ensures protection of grains for extended periods.
Economical Solution
Low cost per ton of storage compared to other silo types.
Efficient Grain Management
With aeration, temperature monitoring, and sweep augers for smooth operation.
Customizable Design
Tailored to meet specific storage needs and site conditions.
Applications
- Grain terminals and warehouses
- Flour mills and feed mills
- Breweries and distilleries
- Port storage facilities
- Oilseed processing plants
- Agro-industries and cooperatives
| Diameter (m) | Height (m) | Volume (m³) | Wheat t (0.78) | Maize t (0.72) | Paddy (0.62) |
|---|---|---|---|---|---|
| 8.40 | 8 | 443.34 | 345.81 | 319.21 | 274.87 |
| 8.40 | 10 | 554.18 | 432.26 | 399.01 | 343.59 |
| 8.40 | 12 | 665.01 | 518.71 | 478.81 | 412.31 |
| 8.40 | 14 | 775.85 | 605.16 | 558.61 | 481.03 |
| 8.40 | 16 | 886.68 | 691.61 | 638.41 | 549.74 |
| 10.00 | 8 | 628.32 | 490.09 | 452.39 | 389.56 |
| 10.00 | 10 | 785.40 | 612.61 | 565.49 | 486.95 |
| 10.00 | 12 | 942.48 | 735.13 | 678.58 | 584.34 |
| 10.00 | 14 | 1099.56 | 857.65 | 791.68 | 681.73 |
| 10.00 | 16 | 1256.64 | 980.18 | 904.78 | 779.11 |
| 10.00 | 18 | 1413.72 | 1102.70 | 1017.88 | 876.50 |
| 12.00 | 10 | 1130.97 | 882.16 | 814.30 | 701.20 |
| 12.00 | 12 | 1357.17 | 1058.59 | 977.16 | 841.44 |
| 12.00 | 14 | 1583.36 | 1235.02 | 1140.02 | 981.68 |
| 12.00 | 16 | 1809.56 | 1411.45 | 1302.88 | 1121.93 |
| 12.00 | 18 | 2035.75 | 1587.89 | 1465.74 | 1262.17 |
| 14.00 | 10 | 1539.37 | 1200.59 | 1108.80 | 953.26 |
| 14.00 | 12 | 1847.25 | 1441.06 | 1328.22 | 1145.39 |
| 14.00 | 14 | 2155.12 | 1680.99 | 1551.69 | 1334.18 |
| 14.00 | 16 | 2462.99 | 1920.53 | 1776.93 | 1525.26 |
| 14.00 | 18 | 2770.87 | 2161.28 | 1995.03 | 1717.94 |
| 14.00 | 20 | 3078.74 | 2400.82 | 2216.28 | 1909.15 |
| 16.00 | 10 | 2010.63 | 1568.28 | 1447.52 | 1246.58 |
| 16.00 | 12 | 2412.76 | 1881.93 | 1736.91 | 1496.90 |
| 16.00 | 14 | 2814.89 | 2195.58 | 2026.31 | 1747.22 |
| 16.00 | 16 | 3217.02 | 2509.05 | 2316.25 | 1994.54 |
| 16.00 | 18 | 3619.15 | 2822.62 | 2606.21 | 2243.86 |
| 16.00 | 20 | 4021.28 | 3136.42 | 2896.52 | 2493.20 |
| 18.00 | 10 | 2544.69 | 1982.85 | 1832.98 | 1576.51 |
| 18.00 | 12 | 3053.63 | 2380.83 | 2198.61 | 1892.25 |
| 18.00 | 14 | 3562.57 | 2777.80 | 2565.06 | 2206.79 |
| 18.00 | 16 | 4071.51 | 3176.77 | 2931.88 | 2524.33 |
| 18.00 | 18 | 4580.45 | 3572.96 | 3297.92 | 2839.68 |
| 18.00 | 20 | 5089.39 | 3969.32 | 3664.76 | 3154.22 |
| 22.00 | 12 | 4546.39 | 3544.79 | 3273.40 | 2818.18 |
| 22.00 | 14 | 5304.12 | 4130.21 | 3818.96 | 3286.56 |
| 22.00 | 16 | 6061.85 | 4726.65 | 4364.33 | 3758.95 |
| 22.00 | 18 | 6819.58 | 5318.26 | 4909.05 | 4226.11 |
| 22.00 | 20 | 7577.32 | 5910.09 | 5456.00 | 4696.12 |
| 24.00 | 12 | 5430.89 | 4231.30 | 3909.04 | 3367.15 |
| 24.00 | 14 | 6336.05 | 4940.16 | 4564.03 | 3926.32 |
| 24.00 | 16 | 7241.20 | 5647.14 | 5206.47 | 4483.54 |
| 24.00 | 18 | 8146.35 | 6354.17 | 5854.29 | 5047.16 |
| 24.00 | 20 | 9051.50 | 7060.17 | 6523.08 | 5612.93 |
| 26.00 | 12 | 6367.07 | 4963.88 | 4582.82 | 3948.61 |
| 26.00 | 14 | 7428.24 | 5793.59 | 5348.92 | 4603.45 |
| 26.00 | 16 | 8490.42 | 6622.72 | 6112.70 | 5253.06 |
| 26.00 | 18 | 9552.60 | 7452.03 | 6878.87 | 5901.61 |
| 26.00 | 20 | 10614.77 | 8278.55 | 7642.62 | 6576.16 |
| 28.00 | 12 | 7381.27 | 5756.39 | 5310.09 | 4573.39 |
| 28.00 | 14 | 8611.48 | 6719.00 | 6199.04 | 5338.96 |
| 28.00 | 16 | 9841.69 | 7670.60 | 7085.01 | 6099.85 |
| 28.00 | 18 | 11071.90 | 8625.08 | 7965.77 | 6864.98 |
| 28.00 | 20 | 12302.11 | 9595.65 | 8857.52 | 7625.31 |
| 30.00 | 12 | 8482.32 | 6615.41 | 6107.68 | 5258.03 |
| 30.00 | 14 | 9896.05 | 7718.32 | 7125.31 | 6130.35 |
| 30.00 | 16 | 11309.77 | 8822.61 | 8142.99 | 7001.06 |
| 30.00 | 18 | 12723.50 | 9921.18 | 9160.92 | 7882.37 |
| 30.00 | 20 | 14137.22 | 11023.33 | 10178.40 | 8760.99 |
| 32.00 | 14 | 11270.92 | 8794.32 | 8114.26 | 6990.07 |
| 32.00 | 16 | 12881.05 | 10036.42 | 9256.36 | 7977.05 |
| 32.00 | 18 | 14491.18 | 11296.12 | 10433.65 | 8985.53 |
| 32.00 | 20 | 16101.31 | 12558.02 | 11592.94 | 9983.81 |
